Ultra and Extreme Narrow Bezel
Narrow Bezel (UNB: Ultra Narrow Bezel, ENB: Extreme Narrow Bezel) displays feature near seamless combined bezel of 1.7mm – 3.5mm. This Narrow tiled gap makes for truly stunning arrays at any size.
Anti-Glare coating and Surface Treatment
Like all CNTech Display video wall models, Video wall displays feature substantial Anti-Glare coating. This allows content to shine through in virtually any indoor application. Hard-coating surface treatment lends durability to displays that may be placed in high-traffic, public settings.
Optional Auto Condition Reporting (ACR) Lite System
ACR Lite is a basic version of our Auto Condition Reporting diagnostic/monitoring tool for video wall displays. Real-time status readouts for each display can be gathered on the ACR Hub (a device which sits in the RS-232 control path), on a PC running ACR software, or on an Android tablet or mobile device. From there, users can gather real-time information such as ACR network connectivity, internal display temperature, power state, and input activity. The ACR Android application also allows users to treat their phone as a remote controller, with power on/off, OSD menu access and other simple control functions.
CNTech là nhà phân phối màn hình quảng cáo uy tín, chất lượng tại thị trường Việt Nam. Với nhiều năm kinh nghiệm trong lĩnh vực cùng với đội ngũ nhân viên tư vấn, kỹ thuật được đào tạo và huấn luyện tốt chắc chắn sẽ mang đến cho bạn một sự trải nghiệm về phong cách phục vụ chuyên nghiệp và tận tình nhất.
CNTech Digital Signage Solution
Liên hệ với chúng tôi để nhận được hỗ trợ nhanh và tốt nhất: 0909 39 29 38
Email: sales@cntech.com.vn
THÔNG SỐ KỸ THUẬT
| Model Number | CN49MLU | CN49HLU | CN49MLE | CN49HLE |
| Screen Size | 49" | 49" | 49" | 49" |
| Panel Technology | IPS / Direct-LED backlight | IPS / Direct-LED backlight | IPS / Direct-LED backlight | IPS / Direct-LED backlight |
| Resolution | 1920 x 1080 | 1920 x 1080 | 1920 x 1080 | 1920 x 1080 |
| Pixel Pitch (mm) | 0.55926 (H) x 0.55926 (V) | 0.55926 (H) x 0.55926 (V) | 0.55926 (H) x 0.55926 (V) | 0.55926 (H) x 0.55926 (V) |
| Brightness (Typ.) | 500nit | 700nit | 500nit | 700nit |
| Contrast Ratio (Typ.) | 1,300:1 / 500,000:1 (DCR) | 1,300:1 / 500,000:1 (DCR) | 1,300:1 / 500,000:1 (DCR) | 1,300:1 / 500,000:1 (DCR) |
| Displayable Colors | 10bit(D), 1.07 Million colors | 10bit(D), 1.07 Million colors | 10bit(D), 1.07 Million colors | 10bit(D), 1.07 Million colors |
| Viewing Angle | 178° (min) / 178° (min) | 178° (min) / 178° (min) | 178° (min) / 178° (min) | 178° (min) / 178° (min) |
| Response Time | 12ms | 12ms | 12ms | 12ms |
| Aspect Ratio | 16:9 | 16:9 | 16:9 | 16:9 |
| Tiled Bezel Width | 3.5 mm (combined) | 3.5 mm (combined) | 1.8 mm (combined) | 1.8 mm (combined) |
| Dimension (W x H x D) | 42.42” x 23.93” x 3.25” | 42.42” x 23.93” x 3.25” | 42.35” x 23.86” x 3.22” | 42.35” x 23.86” x 3.22” |
| VESA Pattern (mm) | 600 X 400 | 600 X 400 | 600 X 400 | 600 X 400 |
| Electrical Ratings | AC 100 - 240V (50/60Hz) | AC 100 - 240V (50/60Hz) | AC 100 - 240V (50/60Hz) | AC 100 - 240V (50/60Hz) |
| Power Consumption | 90W / 1.1A | 150W / 1.8A | 90W / 1.1A | 150W / 1.8A |
| Operating Temperature | 32°F - 104°F | 32°F - 104°F | 32°F - 104°F | 32°F - 104°F |
| Operating Humidity Range | 10~80% | 10~80% | 10~90% | 10~90% |
| Possible Display Type | Landscape and Portrait-Compatible | Landscape and Portrait-Compatible | Landscape and Portrait-Compatible | Landscape and Portrait-Compatible |
| Industrial Reliability | 60,000+ Hours | 60,000+ Hours | 60,000+ Hours | 60,000+ Hours |
| Display Port | 1 x Input | 1 x Input | 1 x Input | 1 x Input |
| HDMI | 1 x Input | 1 x Input | 1 x Input | 1 x Input |
| DVI | 1 x Input, 1 x output | 1 x Input, 1 x output | 1 x Input, 1 x output | 1 x Input, 1 x output |
| VGA | 1 x Input, 1 x output | 1 x Input, 1 x output | 1 x Input, 1 x output | 1 x Input, 1 x output |
| RS232 | 1 x Input, 1 x output | 1 x Input, 1 x output | 1 x Input, 1 x output | 1 x Input, 1 x output |
| ACR Lite System | Optional | Optional | Optional | Optional |
| ACR Hub | Optional | Optional | Optional | Optional |
