LED Panel Ultra Slim
A True 16:9 LED Display Unit
High definition display
The world's first golden 16:9 ratio standard cabinet, which is in line with human eye pupil ratio 2K, 4K and 8k compatible
High grey scale under low brightness
Wide viewing angle
Vertical 165° / Horizontal 165° to reach a wider audience
Ultra slim and light design enables efficient maintenance
Ultra-light and slim Die-casting aluminum cabinet facilitate user-friendly maintenance.
Color temperature adjustable from 2000K to 9300K
Low radiation and noiseless technology
Passed the EMC-class B standard with noiseless technology to ensure silent environment capabilities.
THÔNG SỐ KỸ THUẬT
Item | Ultra Slim 0.9 | Ultra Slim 1.2 | Ultra Slim 1.5 | Ultra Slim 1.9 |
---|---|---|---|---|
Cabinet Resolution (pixels) | 640×360 | 480×270 | 384×216 | 320×180 |
Cabinet Size (mm) |
W609.92×H343.08×D75 |
W609.92×H343.08×D75 |
W609.92×H343.08×D75 |
W609.92×H343.08×D75 |
Material | Die-cast | Die-cast | Die-cast | Die-cast |
Brightness (cd/sqm) | 600 | 600 | 600 | 600 |
Weight (kg/cabinet) | 7.5 | 7.5 | 7.5 | 7.5 |
