Video Wall LG 55SVH7E

  1. Type: D-LED DID
  2. Application: indoor
  3. Panel size:  55”
  4. LCD Screen: LG
  5. Narrow bezel: 0.44 mm (Even)
  6. Resolution: Full HD 1920x1080 and 3840×2160
  7. Brightness: 700 cd/m2
  8. Full screen mode: 178 / 178
  9. Function: Photo slides, Movie full HD, Music Playback
  10. Interface Type:  LAN/Wifi/3G, USB, VGA, HDMI

Market: shopping malls, retail stores, restaurants, hotels ...

ID: 55SVH7E
















CNTech is a distributor of high quality advertising display in Vietnam market. With many years of experience in the field together with consulting staff, well trained and trained technicians will surely bring you the most professional and enthusiastic service experience.

CNTech Digital Signage Solution

Contact us for the fastest and best support: 0909 39 29 38

Email: sales@cntech.com.vn

Panel

Screen Size

55”

Native Resolution

1,920 x 1,080 (FHD)

Brightness(Module, Typ., cd/m²)

700 nit

Orientation

Landscape & Portrait

Connectivity

Input

HDMI, DP, DVI-D, RGB, Audio In, USB 2.0

Output

DP, Audio Out

External Control

RS232C In/Out, RJ45 In/Out, IR Receiver In

Physical Specification

Bezel Width

0.44 mm (Even)

Monitor Dimension (W x H x D)

1,210.51 x 681.22 x 86.5 mm

Weight (Head)

16.8 kg

Carton Dimensions (W x H x D)

1,353.0 x 855.0 x 263.0 mm

Packed Weight

23.6 kg

Handle

Yes

VESA™ Standard Mount Interface

600 x 400 mm

Environment Conditions



Operation Temperature

0°C to 40°C

Operation Humidity

10 % to 80 %

Power Consumption



Power Supply

100-240V~, 50/60Hz

Power Type

Built-In Power

Typ. / Max

170 W / 220 W

Standard (Certification)

Safety

UL / cUL / CB / TUV / KC

EMC

FCC Class "A" / CE / KCC

ErP / Energy Star

NA / Yes (Energy Star 7.0)

Media Player Compatibility

OPS type compatible

No

External Media player Attatchable

Yes

Accessory



Basic

Remote controller, Power cable, DP cable, IR receiver, RS-232C cable, Tiling guide, Screw

Optional

WM-L640V (Landscape), WM-P640V (Portrait), Frame kit (Horizontal: FK-55V10 / Vertical: FK-55V20)
