Standard Touch Screen Kiosk CN-KT03

  1. Model Number: CN-KT03
  2. Type: TFT, Infrared, LCD Touch Screen
  3. Application: Indoor
  4. Panel size: 22'' 32'' 42" 46" 55" 65" 70" 72'' 84''
  5. Operating System: Window, Android
  6. LCD Screen: Samsung, LG
  7. Resolution: Full HD 1920x1080
  8. Brightness: 450 cd / m2
  9. Full screen mode: 178/178
  10. High quality aluminum alloy casing
  11. Customize split screen into different content
  12. Schedule time auto turn on/off the screen
  13. Interface Type: LAN / Wifi / 3G, USB, VGA, HDMI

Market: shopping malls, retail stores, restaurants, hotels ...

ID: CN-KT03


10-points Touch(multi-character control)

Advertising display screen 10-points touch,≤5mm Explosion Protection Toughened Glass for The Writing Surface, Scratch-resistant,anticollison.It can be operated by hands or any opague item.Both convenient and environmental.

Operating Gesturer(touched freely)

  • Led advertising display can be touched with single hand or two hands.Zoom in/Zoom out,minify/magnify,rotate..
  • It is easy to operate and all is under your control

Computer Function(optional system wireless or wired Internet)

Android or Windows system available.A slight touch on the screen can operate the kiosk,which interacts with you and equip freely.All-in-one design is convenient for the maintain and upgrade.

Programming(to release the program and control numbers of terminals)

Split Screen(advertising screen supports remote control)

  • Remotely manage devices in different locations by internet.
  • Support split screen, one screen window is divided into several sections for different usages.



CNTech is a distributor of high quality advertising display in Vietnam market. With many years of experience in the field together with consulting staff, well trained and trained technicians will surely bring you the most professional and enthusiastic service experience.

CNTech Digital Signage Solution

Contact us for the fastest and best support: 0909 39 29 38

Email: sales@cntech.com.vn

TECHNICAL SPECIFICATIONS

Model

CN-KT03 PC Version

CN-KT03 Android Version









Screen

Panel Brand

Samsung & LG Full New 100% A+ Grade Brand Panel

Panel size

55"

Display size

1209mm(H)×680mm(V)

Display ratio

16:9

Resolution

1080*1920

Viewing angle

178°/178°(H/V)

Color

16.7M

Backlits

LED

Brightness

450  cd/m2

Contrast

5000:1







OS System

Standard:main board:G61 CPU:G620

CPU:A10  1.8 Single-core

RAM:KINSTON2GB  Hard disk:500GB

RAM:8G

Superior:main board:G61 CPU:I3 2120



RAM:KINSTON 4GB  Hard disk:500GB



Operation

Windows 7

Android 4.2(can be upgraded)

Connection to network

RJ45, 3G, WIFI (optional)

RJ45 ,3G,WIFI (optional)





Touch Screen

system



Touch screen

Infrared touch screen

(touch foil, capacitive)



Infrared touch screen

(touch foil, capacitive)



Touch ways

finger,touch pen

finger,touch pen

Touch dots

1/2/4/6 dots (optional)

2 dots

Durability

More than 50 million touch

More than 50 million touch



Power

Power

140W

120W

Voltage

AC100-240V 50/60HZ

AC100-240V 50/60HZ

Stability

good

good







Instructions

Interface

VGA/HDMI/USB

HDMI/USB/SD

Working

temperature

-5°C-75°C

-5°C-75°C

Material

Aluminum alloy,tempered glass

Aluminum alloy,tempered glass

Surface

Spraying,frosted aluminum

Spraying,frosted aluminum

Size

Undetermined

Undetermined

Wight

Undetermined

Undetermined



Body

Shell

Mild-steel sheet. Thickness:1.0-1.5mm.

Color

Black , white , silver or customized colors

Packing

By carton with foam inside & woonden



Optional Functions

Anti-dazzle

3G  Capability

Human sensor

Fan, temperature and light sensor

Functions and Applications

  • Support Format: Photo format, JPEG,BMP,PNG. Video format, MPG,MPEG,DAT,MP4,AVI,VOB,TRP,TP,M2TS,TS,RM,RMVB,MKV,DIVX,MOTONJPEG,ASF,WMV,FLV. Music format, MP3,AAC-LC,WMA.
  • Automatical and cycle play when power on,play follow data name or playlist.
  • 5 groups of automatic power on/off with volume can be set. Daily and weekly timer power on/off.
  • Multiple time display mode.
  • Support photo show time, and various slide modes can be set.
  • Support photo/music/photo/video/music/all/playlist.
  • Support playlist: play photo/video/music and subtitles in the specified time.
  • Support one roll.txt can set on or off, multiple marguee color and back color.
  • Support photo/video all repeat, single repeat, or not repeat.
  • Support power resume function.
  • Support USB high speed update information, support USB upgrade function.
  • Effect adjust: brightness, contrast, color, sharpness, backlight, noise reduction, video mode.
  • Support check the data of photo or video.
  • AD insert: 1-60 minute, up to 9 AD can be insert.
  • New function: Can be set split-screen 1 to 10 sections for broadcasting video and photos, free to set the sections. (request this function should be informed when ordering).
