Standard Advertising Display LG SM5KE Series

  1. Model: SM5KE
  2. Application: indoor
  3. Panel size:  32", 43", 49" 55”
  4. LCD Screen: LG
  5. Bezel: 11.9 mm (T/R/L), 18 mm (B)
  6. Resolution: Full HD 1920x1080 and 3840×2160
  7. Brightness: 450 cd/m2
  8. Full screen mode: 178 / 178
  9. Built-in Speaker : 10W + 10W
  10. Function: Photo slides, Movie full HD, Music Playback
  11. Interface Type:  HDMI(3)/ DP/ DVI-D/ USB 3.0/ RS232C/ RJ45/ Audio/ IR

Market: shopping malls, retail stores, restaurants, hotels ...

ID: SM5KE



Simple Set-up & Customization

The LG webOS smart signage platform supports HTML5 as a web-based platform and offers SDK (Software Development Kit), so SIs can easily build and execute their own apps. Also, it is easy to use with intuitive menu and usable without instructions, as all of signage-related functions can be indexed in one menu.


Video Streaming

SM5KE series can play real-time streaming content by supporting various types of IP video streaming protocols such as RTSP/RTP/HLS and UDP Multicast*. It makes users feel easy to manage content as it is free from capacity limits for content playback, and provides live broadcasts in real time.


Multi Screen Mode

PBP (Picture-By-Picture) and PIP (Picture-In-Picture) enables up to two divided split screens in landscape or portrait display format enabling users to more flexibly allocate space for each content source.

Wireless Solutions

  • Content Sharing Mirroring among devices is more convenient on a Wi-Fi network.

  • Real-time Promotion With Beacon and Bluetooth Low Energy (BLE), retail stores can provide coupons and information in real-time.


Quick Web Access via Proxy Server

Web access speed and security can be improved by supporting proxy server. Managers can not only block unwanted websites, but also quickly access to resources using caches.

Secured Network Communication

HTTPS* protocol support ensures secure communication between clients and servers. Content or documents using HTTPS can be shared and displayed on digital signages, so owners can protect their critical business assets from unwelcome pirates.

Conformal Coating

The product can be often unavoidably exposed to dust and water during maintenance. Conformal coating on power board eliminates such troubles by protecting it against dust, iron powder, humidity, etc.



Dimension




Connectivity

CNTech is a distributor of high quality advertising display in Vietnam market. With many years of experience in the field together with consulting staff, well trained and trained technicians will surely bring you the most professional and enthusiastic service experience.

CNTech Digital Signage Solution

Contact us for the fastest and best support: 0909 39 29 38

Email: sales@cntech.com.vn

Panel

32SM5KE

43SM5KE

49SM5KE

55SM5KE

Screen Size

32 inch

43 Inch

49 Inch

55 Inch

Panel Technology

IPS IPS IPS IPS

Aspect Ratio

16:9 16:9 16:9 16:9

Native Resolution

1,920 x 1,080 (FHD)

1,920 x 1,080 (FHD)

1,920 x 1,080 (FHD)

1,920 x 1,080 (FHD)

Brightness(Typ., cd/m²)

450 nit

450 nit

450 nit

450 nit

Contrast Ratio

1,100:1 1,100:1 1,100:1 1,100:1

Viewing Angle (H x V)

178 x 178 178 x 178 178 x 178 178 x 178

Response Time

12 ms (G to G BW), 9.0 ms 12 ms (G to G BW), 9.0 ms  12 ms (G to G BW), 9.0 ms  12 ms (G to G BW), 9.0 ms

Surface Treatment (Haze)

Hard Coating (3H), Anti-glare Treatment of
the Front Polarizer (Haze 1% (Typ.)
Hard Coating (3H), Anti-glare Treatment of
the Front Polarizer (Haze 1% (Typ.)
Hard Coating (3H), Anti-glare Treatment of
the Front Polarizer (Haze 1% (Typ.)
Hard Coating (3H), Anti-glare Treatment of
the Front Polarizer (Haze 1% (Typ.)

Life Time (Typ.)

50,000 Hrs 50,000 Hrs 50,000 Hrs 50,000 Hrs

Guaranteed Operating Hours

18 Hrs 18 Hrs 18 Hrs 18 Hrs

Orientation

Landscape & Portrait

Landscape & Portrait

Landscape & Portrait

Landscape & Portrait

Connectivity

Input

HDMI (3), DP, DVI-D, Audio, USB 3.0

HDMI (3), DP, DVI-D, Audio, USB 3.0

HDMI (3), DP, DVI-D, Audio, USB 3.0

HDMI (3), DP, DVI-D, Audio, USB 3.0

Output

DP (SST), Audio(Off/Fixed/Variable)

DP (SST), Audio(Off/Fixed/Variable)

DP (SST), Audio(Off/Fixed/Variable)

DP (SST), Audio(Off/Fixed/Variable)

External Control

RS232C In/Out, RJ45 In, IR Receiver In

RS232C In/Out, RJ45 In, IR Receiver In

RS232C In/Out, RJ45 In, IR Receiver In

RS232C In/Out, RJ45 In, IR Receiver In

Physical Specification

Bezel Color

Black Black Black Black

Bezel Width

13 mm (T/R/L), 18 mm (B)

11.9 mm (T/R/L), 18 mm (B)

11.9 mm (T/R/L), 18 mm (B)

11.9 mm (T/R/L), 18 mm (B)

Monitor Dimension (W x H x D)

729.4 x 428.9 x 55.5 mm

969.6 x 563.9 x 54 mm

1,102.2 x 638.5 x 54 mm

1,238 x 714.9 x 54 mm

Weight (Head)

5.4 kg

10.0 Kg

14.3 Kg

17.5 Kg

Carton Dimensions (W x H x D)

810 x 510 x 132 mm

1,052 x 650 x 123 mm

1,197 x 760 x 166 mm

1,330 x 807 x 170 mm

Packed Weight

6.7 kg

12.6 Kg

17.4 Kg

21.7 Kg

Monitor with Optional Stand Dimensions

729.4 x 481 x 154.2 mm

969.6 x 622.2 x 193 mm

1102.2 x 696.8 x 219.6 mm

1,238m x 773.4 x 219.6 mm

Weight (Head+Stand)

6.2 Kg

12.5 Kg

17.6 Kg

20.8 Kg

VESA™ Standard Mount Interface

200 x 200 mm

200 x 200 mm

300 x 300 mm

300 x 300 mm

Environment Conditions









Operation Temperature

0°C to 40°C

0°C to 40°C

0°C to 40°C

0°C to 40°C

Operation Humidity

10 % to 80 %

10 % to 80 %

10 % to 80 %

10 % to 80 %

Power Consumption









Power Supply

100-240V~, 50/60Hz

100-240V~, 50/60Hz

100-240V~, 50/60Hz

100-240V~, 50/60Hz

Power Type

Built-In Power

Built-In Power

Built-In Power

Built-In Power

Typ. / Max

60W / 85W

75W / 95W

85W / 105W

100W / 115W

Sound

Speaker

20 W (10 W x 2)

20 W (10 W x 2)

20 W (10 W x 2)

20 W (10 W x 2)

Standard (Certification)

Safety

IEC 60950-1 / EN 60950-1 / UL 60950-1

IEC 60950-1 / EN 60950-1 / UL 60950-1

IEC 60950-1 / EN 60950-1 / UL 60950-1

IEC 60950-1 / EN 60950-1 / UL 60950-1

EMC

FCC Class "A" / CE / KCC

FCC Class "A" / CE / KCC

FCC Class "A" / CE / KCC

FCC Class "A" / CE / KCC

ErP / Energy Star

Yes / Yes (Energy Star 7.0)

Yes / Yes (Energy Star 7.0)

Yes / Yes (Energy Star 7.0)

Yes / Yes (Energy Star 7.0)

Media Player Compatibility

OPS type compatible

Yes

Yes

Yes

Yes

External Media player Attatchable

Yes (MP500 / MP700)

Yes (MP500 / MP700)

Yes (MP500 / MP700)

(MP500 / MP700)

Accessory









Basic

Remote controller, Power cable,
DP cable, IR receiver,
RS-232C cable, Tiling guide, Screw

Remote controller, Power cable,
DP cable, IR receiver,
RS-232C cable, Tiling guide, Screw

Remote controller, Power cable,
DP cable, IR receiver,
RS-232C cable, Tiling guide, Screw

Remote controller, Power cable,
DP cable, IR receiver,
RS-232C cable, Tiling guide, Screw

Optional

WM-L640V (Landscape),
WM-P640V (Portrait),
Frame kit (Horizontal: FK-55V10 / Vertical: FK-55V20)

WM-L640V (Landscape),
WM-P640V (Portrait),
Frame kit (Horizontal: FK-55V10 / Vertical: FK-55V20)

WM-L640V (Landscape),
WM-P640V (Portrait),
Frame kit (Horizontal: FK-55V10 / Vertical: FK-55V20)

WM-L640V (Landscape),
WM-P640V (Portrait),
Frame kit (Horizontal: FK-55V10 / Vertical: FK-55V20)
