Standard Advertising Display LG SE3KE Series

  1. Model: SE3KE
  2. Application: indoor
  3. Panel size:  32", 43", 49" 55”
  4. LCD Screen: LG
  5. Bezel: 11.9 mm (T/R/L), 18 mm (B)
  6. Resolution: Full HD 1920x1080 and 3840×2160
  7. Brightness: 350 cd/m2
  8. Full screen mode: 178 / 178
  9. Built-in Speaker : 10W + 10W
  10. Function: Photo slides, Movie full HD, Music Playback
  11. Interface Type:  HDMI(3)/ DP/ DVI-D/ USB 3.0/ RS232C/ RJ45/ Audio/ IR

Market: shopping malls, retail stores, restaurants, hotels ...

ID: SE3KE


User-Friendly Menu for Digital Signage

With the signage dedicated home menu, users can check key information related to displays at a glance. On the bottom, the content management menu is provided, letting you explore and play available content and set playlists with desired schedules using a remote controller.

USB Content Scheduling & Data Cloning

USB content scheduling and cloning makes managing multiple displays more efficient for optimal content playback and operation, since users don’t have to set up each display one by one. Once users copy data to a USB in one display, it will be easily distributed to others through a USB plug-in.

Efficient Operation

  • Stand-by Screen Mode The SE3KE series partially keeps power-on status controllable by network while the screen is turned off, enabling efficient power management.
  • Scheduled Screen Wash ISM (Image Sticking Minimization) mode supports users in setting up periods and times to refresh the screen to prevent the occurrence of image sticking.
  • 18/7 Operation The SE3KE series can be operated for 18 hours a day, which provides users with the flexibility to allocate and operate it in places that are open for long periods of time.

A Wide Range of Interfaces

Thanks to its high compatibility with diverse interfaces, users can select among various input/output sources for optimal content playback and control.

Compatibility with AV Control Systems

The SE3KE series has been certified Crestron Connected for a higher level of compatibility with professional AV controls to achieve seamless integration and automated control1, boosting business management efficiency.

Detachable Logo & Built-in Speaker

The detachable logo makes it easy for the user to arrange the signage. Also, sounds can be played from built-in speakers, offering viewers various multi-media experiences.

Conformal Coating

The product can be often unavoidably exposed to dust and water during maintenance. Conformal coating on power board eliminates such circumstances by protecting it against dust, iron powder, humidity, etc.



Dimension


Connectivity

CNTech is a distributor of high quality advertising display in Vietnam market. With many years of experience in the field together with consulting staff, well trained and trained technicians will surely bring you the most professional and enthusiastic service experience.

CNTech Digital Signage Solution

Contact us for the fastest and best support: 0909 39 29 38

Email: sales@cntech.com.vn

Panel

32SE3KE

43SE3KE

49SE3KE

55SE3KE

Screen Size

32 inch

43 Inch

49 Inch

55 Inch

Panel Technology

IPS IPS IPS IPS

Aspect Ratio

16:9 16:9 16:9 16:9

Native Resolution

1,920 x 1,080 (FHD)

1,920 x 1,080 (FHD)

1,920 x 1,080 (FHD)

1,920 x 1,080 (FHD)

Brightness(Typ., cd/m²)

350 nit

350 nit

350 nit

350 nit

Contrast Ratio

1,100:1 1,100:1 1,100:1 1,100:1

Viewing Angle (H x V)

178 x 178 178 x 178 178 x 178 178 x 178

Response Time

12 ms (G to G BW), 9.0 ms 12 ms (G to G BW), 9.0 ms  12 ms (G to G BW), 9.0 ms  12 ms (G to G BW), 9.0 ms

Surface Treatment (Haze)

AGP Haze 1% AGP Haze 1% AGP Haze 1% AGP Haze 1%

Life Time (Typ.)

50,000 Hrs 50,000 Hrs 50,000 Hrs 50,000 Hrs

Guaranteed Operating Hours

18 Hrs 18 Hrs 18 Hrs 18 Hrs

Orientation

Landscape & Portrait

Landscape & Portrait

Landscape & Portrait

Landscape & Portrait

Connectivity

Input

HDMI (2), DP, DVI-D, Audio, USB

HDMI (2), DP, DVI-D, Audio, USB

HDMI (2), DP, DVI-D, Audio, USB

HDMI (2), DP, DVI-D, Audio, USB

Output

Audio(Off/Fixed/Variable)

Audio(Off/Fixed/Variable)

Audio(Off/Fixed/Variable)

Audio(Off/Fixed/Variable)

External Control

RS232C In/Out, RJ45 In, IR In

RS232C In/Out, RJ45 In, IR In

RS232C In/Out, RJ45 In, IR In

RS232C In/Out, RJ45 In, IR In

Physical Specification

Bezel Color

Black Black Black Black

Bezel Width

13 mm (T/R/L), 18 mm (B)

11.9 mm (T/R/L), 18 mm (B)

11.9 mm (T/R/L), 18 mm (B)

11.9 mm (T/R/L), 18 mm (B)

Monitor Dimension (W x H x D)

729.4 x 428.9 x 55.5 mm

969.6 x 563.9 x 54 mm

1,102.2 x 638.5 x 54 mm

1,238 x 714.9 x 54 mm

Weight (Head)

5.4 kg

10.0 Kg

14.3 Kg

17.5 Kg

Carton Dimensions (W x H x D)

810 x 510 x 132 mm

1,052 x 650 x 123 mm

1,197 x 760 x 166 mm

1,330 x 807 x 170 mm

Packed Weight

6.7 kg

12.6 Kg

17.4 Kg

21.7 Kg

Monitor with Optional Stand Dimensions

729.4 x 481 x 154.2 mm

969.6 x 622.2 x 193 mm

1102.2 x 696.8 x 219.6 mm

1,238m x 773.4 x 219.6 mm

Weight (Head+Stand)

6.2 Kg

12.5 Kg

17.6 Kg

20.8 Kg

VESA™ Standard Mount Interface

200 x 200 mm

200 x 200 mm

300 x 300 mm

300 x 000 mm

Environment Conditions









Operation Temperature

0°C to 40°C

0°C to 40°C

0°C to 40°C

0°C to 40°C

Operation Humidity

10 % to 80 %

10 % to 80 %

10 % to 80 %

10 % to 80 %

Power Consumption









Power Supply

100-240V~, 50/60Hz

100-240V~, 50/60Hz

100-240V~, 50/60Hz

100-240V~, 50/60Hz

Power Type

Built-In Power

Built-In Power

Built-In Power

Built-In Power

Typ. / Max

40W / 80W

55W / 90W

60W / 90W

65W / 100W

Sound

Speaker

20 W (10 W x 2)

20 W (10 W x 2)

20 W (10 W x 2)

20 W (10 W x 2)

Standard (Certification)

Safety

IEC 60950-1 / EN 60950-1 / UL 60950-1

IEC 60950-1 / EN 60950-1 / UL 60950-1

IEC 60950-1 / EN 60950-1 / UL 60950-1

IEC 60950-1 / EN 60950-1 / UL 60950-1

EMC

FCC Class "A" / CE / KCC

FCC Class "A" / CE / KCC

FCC Class "A" / CE / KCC

FCC Class "A" / CE / KCC

ErP / Energy Star

Yes / Yes (Energy Star 7.0)

Yes / Yes (Energy Star 7.0)

Yes / Yes (Energy Star 7.0)

Yes / Yes (Energy Star 7.0)

Media Player Compatibility

OPS type compatible

Yes

Yes

Yes

Yes

External Media player Attatchable

Yes (MP500 / MP700)

Yes (MP500 / MP700)

Yes (MP500 / MP700)

(MP500 / MP700)

Accessory









Basic

Remote controller, Power cable,
DP cable, IR receiver,
RS-232C cable, Tiling guide, Screw

Remote controller, Power cable,
DP cable, IR receiver,
RS-232C cable, Tiling guide, Screw

Remote controller, Power cable,
DP cable, IR receiver,
RS-232C cable, Tiling guide, Screw

Remote controller, Power cable,
DP cable, IR receiver,
RS-232C cable, Tiling guide, Screw

Optional

WM-L640V (Landscape),
WM-P640V (Portrait),
Frame kit (Horizontal: FK-55V10 / Vertical: FK-55V20)

WM-L640V (Landscape),
WM-P640V (Portrait),
Frame kit (Horizontal: FK-55V10 / Vertical: FK-55V20)

WM-L640V (Landscape),
WM-P640V (Portrait),
Frame kit (Horizontal: FK-55V10 / Vertical: FK-55V20)

WM-L640V (Landscape),
WM-P640V (Portrait),
Frame kit (Horizontal: FK-55V10 / Vertical: FK-55V20)
