Interactive Touch Screen Table CN-LCDT2

  1. Model Number: CN-LCDT2
  2. Type: TFT, Infrared, LCD Screen
  3. Application: Indoor
  4. Panel size: 42" 46" 55" 65" 70"
  5. Operating System: Window7, Android
  6. LCD Screen: Samsung & LG Full New 100% A+ Grade Brand Panel
  7. Resolution: Full HD 1920x1080
  8. Brightness: 400 ~ 750 cd / m2
  9. Full screen mode: 178/178
  10. High quality aluminum alloy casing
  11. Schedule time auto turn on/off the screen
  12. Interface Type: USB, VGA, HDMI

Market: shopping malls, retail stores, restaurants, hotels ...

ID: CN-LCDT2


CNTech is a distributor of high quality advertising display in Vietnam market. With many years of experience in the field together with consulting staff, well trained and trained technicians will surely bring you the most professional and enthusiastic service experience.

CNTech Digital Signage Solution

Contact us for the fastest and best support: 0909 39 29 38

Email: sales@cntech.com.vn

Model

CN-LCDT2 PC Version

CN-LCDT2 Android Version









Screen

Panel Brand

Samsung & LG Full New 100% A+ Grade Brand Panel

Panel size

 46"

Display size

573×1019 mm

Display ratio

16:9

Resolution

1080*1920

Viewing angle

178°/178°(H/V)

Color

16.7M

Backlits

LED

Brightness

450-750 cd/m2

Contrast

5000:1







OS System

Standard:main board:G61 CPU:G620

CPU:A10  1.8 Single-core

RAM:KINSTON2GB  Hard disk:500GB

RAN:8G

Superior:main board:G61 CPU:I3 2120



RAM:KINSTON 4GB  Hard disk:500GB



Operation

Windows 7

Android 4.2(can be upgraded)

Connection to network

RJ45, 3G, WIFI (optional)

RJ45 ,3G,WIFI (optional)





Touch Screen

system



Touch screen

Infrared touch screen

(resistive, capacitive)



Infrared touch screen

(resistive, capacitive)



Touch ways

finger,touch pen

finger,touch pen

Touch dots

1/2/4/6 dots (optional)

2 dots

Durability

More than 50 million touch

More than 50 million touch



Power

Power

140W

120W

Voltage

AC100-240V 50/60HZ

AC100-240V 50/60HZ

Stability

good

good







Instructions

Interface

VGA/HDMI/USB

HDMI/USB/SD

Working

temperature

-5°C-75°C

-5°C-75°C

Material

Aluminum alloy,tempered glass

Aluminum alloy,tempered glass

Surface

Spraying,frosted aluminum

Spraying,frosted aluminum

Size

Undetermined

Undetermined

Wight

Undetermined

Undetermined



Body

Shell

Galvanized   steel sheet. Thickness:1.0-1.5mm.

Color

Black , white , silver or customized colors

Packing

By carton with foam inside & woonden



Optional Functions

Anti-dazzle

3G  Capability

Human sensor

Fan, temperature and light sensor

Product Overviews

  • We receive any product size custom services, Existing screen panel size 42" 46" 55" 65" 70".
  • Infrared multi-touch technology allows for highly accurate interactivity in applications, such as enlarging and rotating images; allows up to 5 users at a time.
  • Full HD 1080p (1920x1080) 16:9 LCD Touch Screen Monitor with HDMI, DisplayPort, USB 3.0, and VGA Inputs.
  • Multi-touch, up to 36-point touch.
  • Resistive, capacitive, infrared, optical, acoustic wave touch screen, accurate positioning.
  • Touch-free drift, auto- correction, can be precise operation.
  • Operated by finger, soft touch pen.
  • Microsoft Windows 8 OS; compatible with any single or multi-touch software.
  • High definition. Less demanding on the environment, and high sensitivity. Suitable for a variety of environments.
  • With over one million hits lifetime high performance resistors, capacitors, infrared touch screen without using the mouse and keyboard, just gently with your finger across the screen or click on the computer all operations can be achieved, so that the computer easier to use. Touch the biggest innovation is its use of a computer is a multi-touch technology has completely changed the way people interact with computers.
